IAME 125 cc LEOPARD TaG engine User Manual

18/10/02 mod. C MAN-016 D
18
3.8.9 INSERT THE SPARK PLUG CAP ON
THE SPRING (SEE FIG. 30). INSTALL THE
SPARK PLUG AND THE CAP OVER THE
SPARK PLUG.
?? INSTALL THE SPARK PLUG
?? INSTALL THE SPARK PLUG CAP
MAKING SURE THAT THE SPRING IN
THE CAP IS WELL INSERTED IN THE
SPARK PLUG.
3.9
INSTALL THE INTAKE SILENCER
- MAKE SURE THAT THE FILTER HAS THE
INLET HOLES TOWARDS THE UPPER SIDE.
-
FIX THE FILTER ON THE CARB, WITH A
STEEL CLAMP, AND THE FILTER TO THE
CHASSIS SIDE RAILS WITH PLASTIC
CLAMPS (SEE FIG. 31-32)
Fig.30
Fig.31
Fig.32
