16
MAN-028
3.7.6 CHEK THE ELECTRIC STARTER
CABLE FIXING (SEE FIG. 29) AND
COMPLETE THE FIXING OF THE HARNESS
(SEE FIG. 30).
ATTENTION :
NEVER LET THE HARNESS GET IN TOUCH
WITH THE GROUND OR WITH A ROTATING
PART AS IT COULD BE DAMAGED BEYOND
REPAIR.
3.7.7 CONNECT THE COIL CABLE FROM
THE POWER PACK TO THE TERMINAL ON
THE COIL (SEE FIG. 31).
SUGGESTION:
SEAL THE TERMINAL ON THE COIL WITH
PLASTIC TAPE TO AVOID THAT EVENTUAL
VIBRATIONS MIGHT DISCONNECT THE
TERMINAL.
3.7.8 INSERT THE SPARK PLUG CABLE
THROUGH THE SUPPORT SPRING ON THE
CYLINDER (SEE FIG. 32).
