17
MAN-028
3.7.9 PUNCTURE THE INSULATING
MATERIAL ON THE H.T. CABLE WITH THE
END OF THE CAP SPRING SO THAT THE
SPRING IS IN SURE CONTACT WITH THE
INTERNAL WIRE (SEE FIG. 33).
3.7.10 INSERT THE SPARK PLUG CAP ON
THE SPRING (SEE FIG. 34). INSTALL THE
SPARK PLUG AND THE CAP OVER THE
SPARK PLUG.
• INSTALL THE SPARK PLUG
• INSTALL THE SPARK PLUG CAP
MAKING SURE THAT THE SPRING IN
THE CAP IS WELL INSERTED IN THE
SPARK PLUG.
3.8
INSTALL THE INTAKE SILENCER
- MAKE SURE THAT THE FILTER HAS THE
INLET HOLES TOWARDS THE UPPER SIDE.
- FIX THE FILTER ON THE CARB, WITH A
STEEL CLAMP, AND THE FILTER TO THE
CHASSIS SIDE RAILS WITH PLASTIC
CLAMPS (SEE FIG. 35/36)
Fi
