18
MAN-028
3.9 INSTALL THE EXHAUST
NOTE:
SEE SECTION 9 FOR RECOMMENDATIONS
ON THE IDEAL LENGHT OF THE EXHAUST.
3.9.1 INSTALL THE FLEXIBLE (L= 65mm –
FLEXIBLE COMPLETELY CLOSED) AND THE
EXHAUST HEADER (SEE FIG. 37) AND
CONNECT THE EXHAUST.
3.9.2 INSTALL THE FIBER STRIP AROUND
THE FLEXIBLE AND FIX WITH THE 3
SPRINGS (SEE FIG. 38).
THE ENGINE IS READY TO BE STARTED
Fi
