Iamm NTD36HD - HDD Installation

15
IDE
HDD Installation
1. Push the locker to the direction(“OPEN).
Open up the HDD door slowly.
4. Fix HDD with HDD fixture like below picture.
2. There is HDD fixture inside. Push i
t
forward(#1) slightly and pull it up(#2).
5. Connect IDE cable and power cable
like picture.
3. . Insert HDD carefully inside with NTD36HD
laid down slightly to minimize impact to HDD.
6 Close HDD door and push the locker to the
direction(
“CLOSE”).
POWER
