ibaBM-DPM-S Manual

Issue 2.11

6 DIN rail mounting/dismounting

6.1 Mounting

1. Locate the DIN rail mounting clip on the rear side of the device. Slowly push down and

in so that the bottom part of the mounting clips snaps onto the bottom part of the rail

and firmly fixes the device to the DIN rail.

2. If there is a rule to ground the device, connect the device to the ground (shield connec-

tor X29).

3. Once fixed, connect the 24 V DC power supply to the termination shown on the device.

Ensure that the polarity is correct prior to applying power. Then install the other con-

nections like:

 FO cable to the ibaPDA system

 Network connection via Ethernet TCP/IP or

 USB connection to a PC with Web browser.

Connecting the PROFIBUS cable

Do not connect the PROFIBUS cable until the configuration of the “active slaves“ has been

done correctly.

Please see also chapter 9.4.4.2 “Active Slaves“ tab (Defining the slave addresses)“ and

11.2 „Active slave operating mode“.

Note

If needed, you can activate the PROFIBUS terminating resistor by operating switch S4 or

S5.

6.2 Dismounting

1. Disconnect all external connections from the device.

2. Grasp the device with one hand firmly on the top side. With your free hand, grasp the

bottom of the device and push it lightly down.

3. After that pull the device and lift it up. With this action, the device should free itself from

the DIN rail.
