ibaBM-DPM-S Manual
Issue 2.11
43
Note
The installation might take several minutes. Please do not switch off the device, as this
would interrupt the procedure.
(4)
Activate number of active slaves:
In the same window, you can change the maximum number of active slaves.
This number comprises the slaves of both connections X40 and X41. Please en-
ter two numeric keys, we send you on request. Then, the device detects auto-
matically, how many slaves can be initialized at max. This limit prevents an over-
load of the PROFIBUS sniffer with a number of slaves, not tested, yet.
(5)
Please enter the license keys for the redundancy mode in the “Key 1” and “Key
2” fields. We send you the keys on request. The license is valid for eight active
slaves on a PROFIBUS line. You need to reboot the device.
Note
The upgrade keys in the figure above are just an example.
9.4.6 Define the time
On the “Time” page, you can define the system time. After having entered the time pa-
rameters, you can transfer the current time to the device by clicking on the <submit> but-
ton.
Figure 19: Setting the time
