IBC AHU 800 User Manual

Advanced status - System Feedback
Call Status*
W1 □ W2 □Y1 □ Y2 □G □
*A check box will display to indicate a call for heating and cooling, stage 1 or 2.
4.3.2.4 Fan speed operation
Note
For safety reasons, a switch is built into the door. The switch prevents the fan from
operating if the door is not installed. With the door removed, the appliance's control
board will remain powered, enabling programming of the mobile app.
For fan speed defaults and ranges, see the table below:
Fan Speed Operation
Voltage
Terminal
Description and Defaults Range (CFM)
AHU 800
W1 Heating stage 1 = 500 CFM 150-800 (for mode 1 Stage Heat max
= 1000)
W2 Heating stage 2 = 800 CFM 150-1000 (must be ≥ 1 Stage Heat)
Y1 Cooling stage 1 = 700 CFM 150-800 (for mode 1 Stage AC/HP
max = 1000)
Y2 Cooling stage 2 = 1000 CFM 150-1000 (must be ≥ AC/HP Stage 1)
G Fan on speed = 200 CFM 150-1000
AHU 1200 LV
W1 Heating stage 1 = 600 CFM 180-1000 (for mode 1 Stage Heat
max = 1200)
W2 Heating stage 2 = 960 CFM 180-1200 (must be ≥ 1 Stage Heat)
Y1 Cooling stage 1 = 840 CFM 180-1000 (for mode 1 Stage AC/HP
max = 1200)
Y2 Cooling stage 2 = 1200 CFM 180-1200 (must be ≥ AC/HP Stage 1)
G Fan on speed = 275 CFM 180-1200
AHU1200
68
Section: Operation

IBC AHU 800 Specifications

General

Brand	IBC
Model	AHU 800
Category	Air Handlers
Language	English
