IBC AHU 800 User Manual

Setting Default Description
S1 O/B Control O/B Cool
(Energized for
cooling)
Reversing valve is energized for heating or
cooling based on the setting.
Heat Pump Balance Point
(°F)
14 Calculated based on building heat loss and
selected heat pump.
Static Pressure (inches
WC)
0.5 Based on the ducting system design. Cannot be
adjusted on LV(low velocity)models.
Humidifier Off Sends 24Vto activate the humidifier. Activates
based on the return air sensor.
Dehumidifier On Sends 24Vto activate the dehumidifier. Activates
based on the return air sensor.
Humidity Minimum (%) 15 Based on the humidity sensor in the return air.
Humidity Maximum (%) 45 Based on the humidity sensor in the return air.
FA Damper Off Fresh air damper.
FA Damper Open T (°F) 41 Temperature to open fresh air damper. Uses the
dehumidifier contact. Based on the outdoor
sensor.
Cold House Sentry On Maintains the minimum ambient temperature
inside the house.
Network ID 0 For future development
4.3.2.3 Advanced status
The Advanced Status values will vary based on the current system settings and operating conditions.
See Advanced settings on page 65 for detailed descriptions for each status.
Advanced status - System Feedback
Mode AC/HP Air Temp (°F)
Pump On AC/HP Coil Temp (°F)
Fan RPM Dehumidifier Temp (°F)
Fan CFM Dampers Open
Outdoor Temp (°F) Humidity Target %
Inlet Temperature (°F) Humidity Actual %
Outlet Temperature (°F) Barometer (inHg)
Return Air Temp (°F) Cold House Sentry
Outlet Air Temp (°F)
67
4.3.2 Operational settings in the app
