9-2
IBM Personal Computer User Guide
Identifying system board parts (machine type 2193)
If you plan to add or replace hardware in your computer, you need to know the
layout of the system board. This figure shows an example of the system board of the
machine type 2193 in your computer. The items on the next page correspond to the
numbered locations on the figure.
