Installing the 7316-TF5 17.3-Inch flat panel rack-

mounted monitor and keyboard

Learn how to install the 7316-TF5 17.3-Inch flat panel rack-mounted monitor and keyboard.

The IBM 7316-TF5 17.3-Inch flat panel rack-mounted monitor and keyboard is a flat-panel display and

keyboard tray in one unit. The console unit occupies 1U of space in a rack. You can install an optional

console switch behind the standard console in the rack to attach more than one server to the flat-panel

display and keyboard. The display supports video resolutions from 640 x 480 through 1920 x 1080 at 60

and 75 Hz refresh rates.

Note: The 1 EIA unit in racks are measured in vertical increments of 1.75 inches each. Each 1.75-inch

increment is called an “EIA.” In some countries, the same increment may be referred to as a “U.”

Note: Before you begin installing the IBM 7316-TF5 17.3-Inch flat panel rack-mounted monitor and

keyboard, ensure that you have at least 1 EIA unit of free space above the location where you are

installing the console unit.

Prerequisites

Ensure that you have the following items before you start your installation:

• Flat-head screwdriver

• Rack with at least two units of space

Note: If you do not have a rack that is installed, install the rack. For instructions, see Racks and rack

features (http://www.ibm.com/support/knowledgecenter/POWER9/p9hbf/p9hbf_9xx_kickoff.htm).

7316-TF5 17.3-Inch flat panel rack-mounted monitor and keyboard

specications

The technical specications for the console unit are described in the following list.

Physical Dimensions

H x W x D 1.66x17.17x17.05 inches

4.23x43.61x43.3cm

Weight 11.43 lbs (5.2Kg)

Shipping Dimensions

Package (L x W x D) 22.9 x 7.9 x 24.5 inches

58.1 x 20 x 61.3 cm

Weight 25.3 lbs (11.45 kg)

LCD Panel

Size 17.3-inch diagonal

Type TFT

Characteristics

Brightness 300 cd /m2 (Typ.)
