Table 11. 1600 x 1200 timing chart (continued)
Type Standard
Sync 1.185 μs 192 pixels 1.203 μs 176 pixels
Back porch 1.877 μs 304 pixels 1.915 μs 280 pixels
Front porch 0.395 μs 64 pixels 0.711 μs 104 pixels
Vertical
Total 16.667 ms 1250 lines 16.679 ms 1084 lines
Display 16.000 ms 1200 lines 16.082 ms 1050 lines
Blanking 0.667 ms 50 lines 0.597 ms 39 lines
Sync 0.040 ms 3 lines 0.092 ms 6 lines
Back porch 0.613 ms 46 lines 0.459 ms 30 lines
Front porch 0.013 ms 1 line 0.046 ms 3 lines
Hardware maintenance information
This topic collection provides the information about the IBM Customer-replaceable units (CRUs) for the
console unit and instructions for the replacement parts.
Replaceable components
This topic provides the information about the replaceable components of the 7316-TF4 and 7316-TF5
18.5-Inch Flat Panel Rack-Mounted Monitor and Keyboard console.
Field replaceable units (FRUs) must be replaced only by a trained service technician, unless they are
classied as customer replaceable units (CRUs).
Tier 1 CRU: Replacement of Tier 1 CRUs is your responsibility. If IBM installs a Tier 1 CRU at your request
without a service contract, you will be charged for the installation.
Tier 2 CRU: You may install a Tier 2 CRU yourself or request IBM to install it, at no additional charge,
under the type of warranty service that is designated for your product.
For more information about the terms of the warranty and getting service and assistance, see the
Warranty Information document that comes with the optional device.
IBM CRU part numbers are subject to change without notice. This section contains a listing of the CRU
part numbers that are available as of the date of this document was written.
Installing the 7316-TF4 18.5-Inch Flat Panel Rack-Mounted monitor and keyboard
29
