Table 10. 1440 x 900 timing chart
Type Standard
Timing name 1440 x 900 @ 60 Hz 1440 x 900 @ 75 Hz
Horizontal
frequency and
polarity
55.935 kHz Negative 70.635 kHz Negative
Vertical frequency
and polarity
59.887 Hz Positive 74.984 Hz Positive
Pixel clock 106.5 MHz 136.75 MHz
Scan type Noninterlaced Noninterlaced
Horizontal
Period 17.878 μs 1904 pixels 14.157 μs 1936 pixels
Display 13.521 μs 1440 pixels 10.530 μs 1440 pixels
Blanking 4.357 μs 464 pixels 3.627 μs 496 pixels
Sync 1.427 μs 152 pixels 1.112 μs 152 pixels
Back porch 2.178 μs 232 pixels 1.814 μs 248 pixels
Front porch 0.751 μs 80 pixels 0.702 μs 96 pixels
Vertical
Total 16.698 ms 934 lines 13.336 ms 942 lines
Display 16.090 ms 900 lines 12.741 ms 900 lines
Blanking 0.608 ms 34 lines 0.595 ms 42 lines
Sync 0.107 ms 6 lines 0.085 ms 6 lines
Back porch 0.447 ms 25 lines 0.467 ms 33 lines
Front porch 0.054 ms 3 lines 0.042 ms 3 lines
Table 11. 1600 x 1200 timing chart
Type Standard
Timing name 1600 x 1200 @ 60 Hz 1600 x 1200 @ 75 Hz
Horizontal
frequency and
polarity
75 kHz Positive 65.29 kHz Negative
Vertical frequency
and polarity
60 Hz Positive 59.954 Hz Positive
Pixel clock 162 MHz 146.25 MHz
Scan type Noninterlaced Noninterlaced
Horizontal
Period 13.333 μs 2160 pixels 15.316 μs 2240 pixels
Display 9.877 μs 1600 pixels 11.487 μs 1680 pixels
Blanking 3.457 μs 560 pixels 3.829 μs 560 pixels
28 Power Systems: Installing the 7316-TF4 18.5-Inch and 7316-TF5 17.3-Inch Flat Panel Rack-Mounted
Monitor and Keyboard
