Table 8. 1280 x 800 timing chart (continued)
Type Standard
Sync 1.533 μs 128 pixels 1.202 μs 128 pixels
Back porch 2.395 μs 200 pixels 1.935 μs 206 pixels
Front porch 0.862 μs 72 pixels 0.751 μs 80 pixels
Vertical
Total 16.720 ms 831 lines 13.345 ms 838 lines
Display 16.096 ms 800 lines 12.740 ms 800 lines
Blanking 0.624 ms 31 lines 0.605 ms 38 lines
Sync 0.121 ms 6 lines 0.096 ms 6 lines
Back porch 0.443 ms 22 lines 0.462 ms 29 lines
Front porch 0.060 ms 3 lines 0.048 ms 3 lines
Table 9. 1280 x 1024 timing chart
Type Standard
Timing name 1280 x 1024 @ 60 Hz 1280 x 1024 @ 75 Hz
Horizontal
frequency and
polarity
63.981 kHz Positive 79.976 kHz Positive
Vertical frequency
and polarity
60.02 Hz Positive 75.025 Hz Positive
Pixel clock 108 MHz 135 MHz
Scan type Noninterlaced Noninterlaced
Horizontal
Period 15.630 μs 1688 pixels 12.504 μs 1688 pixels
Display 11.852 μs 1280 pixels 9.481 μs 1280 pixels
Blanking 3.778 μs 408 pixels 3.022 μs 408 pixels
Sync 1.037 μs 112 pixels 1.067 μs 144 pixels
Back porch 2.296 μs 248 pixels 1.837 μs 248 pixels
Front porch 0.444 μs 48 pixels 0.119 μs 16 pixels
Vertical
Total 16.661 ms 1066 lines 13.329 ms 1066 lines
Display 16.005 ms 1024 lines 12.804 ms 1024 lines
Blanking 0.656 ms 42 lines 0.525 ms 42 lines
Sync 0.047 ms 3 lines 0.038 ms 3 lines
Back porch 0.594 ms 38 lines 0.475 ms 38 lines
Front porch 0.016 ms 1 line 0.013 ms 1 line
Installing the 7316-TF4 18.5-Inch Flat Panel Rack-Mounted monitor and keyboard 27
