Figure 29. Installing the service access cover
For a stand-alone system, complete the following steps. Refer to Figure 30 on page 33.
a. Slide the cover (B) on to the system unit as shown.
b. Close the latch release (A) by pushing it in the direction shown.
32
Power Systems: Power Systems: Drive backplanes
