Figure 30. Installing the service access cover
2. For a rack-mounted system, unlock the blue rail safety latches (A) as shown in Figure 31 on page 34
by pushing them inward.
Ensure that the cable management arms can move freely. Ensure that the cables at the rear of the unit
do not catch or bind as you push the unit into the operating position.
Drive backplanes for the 9009-41A, 9009-41G, 9009-42A, 9009-42G, or 9223-42H
33
