Figure 53. Reconnecting the SAS cable in the 12-drive expanded function conguration
For information about SAS cable part numbers, see 9009-41A, 9009-41G, 9009-42A, 9009-42G, or
9223-42H system parts (http://www.ibm.com/support/knowledgecenter/POWER9/p9ecs/
p9ecs_914_924_parts.htm).
6. Fully seat all the front drives and front llers if present into their slots as shown in the following gure.
Push drive lever (A) until the front drive and ller is seated and the lever snaps closed.
Drive backplanes for the 9009-41A, 9009-41G, 9009-42A, 9009-42G, or 9223-42H
