IBM DS4700 Service Manual

DS4700 Express Storage Subsystem and supported storage expansion
enclosure drive cabling schemes
The following sections show cabling schemes for supported storage expansion
enclosures and the DS4700 Express Storage Subsystem:
v “One DS4700 Express and one EXP100 storage expansion enclosure” on page
80
v “One DS4700 Express and two EXP100 storage expansion enclosures” on page
81
v “One DS4700 Express and three or more EXP100 storage expansion enclosures”
on page 82
v “One DS4700 Express and one EXP710 storage expansion enclosure” on page
85
v “One DS4700 Express and two EXP710 storage expansion enclosures” on page
85
v “One DS4700 Express and three or more EXP710 storage expansion enclosures”
on page 86
v “One DS4700 Express and one EXP810 storage expansion enclosure” on page
89
v “One DS4700 Express and two EXP810 storage expansion enclosures” on page
89
v “One DS4700 Express and three or more EXP810 storage expansion enclosures”
on page 90
v “One DS4700 Express and two or more storage expansion enclosures in a mixed
configuration” on page 94
Left ESM
Left ESM
Right ESM
Right ESM
Controller A
Controller B
1
2
2
1
ds470046
Left ESM
Right ESM
Left ESM
Left ESM
Right ESM
Right ESM
Left ESM
Right ESM
2
1
Figure 58. One DS4700 Express and two or more storage expansion enclosures in a mixed
environment — Recommended cabling
Chapter 3. Cabling the storage subsystem 77
