Table 2. Description of Figure 2
Number Description
1 Controller A
2 Controller B
3 Host channels
4 Ethernet ports
5 Serial port
6 Dual-ported drive channel
7 Enclosure ID
Table 3. Description of Figure 3
Number Description
1 Controller A
2 Controller B
3 Host channels
4 Ethernet ports
5 Serial port
6 Dual-ported drive channel
7 Enclosure ID
ds470004
345
6
7
2
3
4
5 6
1
7
Figure 2. Back view; connectors, switch, ports, enclosure ID on model 70
ds470016
2
3
4
5 6
1
7
3456
7
Figure 3. Back view; connectors, switch, ports, enclosure ID on model 72
