spring-loaded pin snaps into place.
10. Place the cable-management arm on the support arm. Pull out the cable-management arm pin (1),
and then slide the cable-management arm tab (2) into the slot on the inside of the slide rail. Push the
tab until it snaps into place. Pull out the other cable-management arm pin (3), and then slide that
cable management arm tab into the slot (4) on the outside of the slide rail. Push the tab until it snaps
into place.
11. Attach the power cords and other cables to the rear of the server (including keyboard, monitor, and
mouse cables, if required). Route the cables and power cords on the cable-management arm (1) and
secure them with cable ties or hook-and-loop fasteners.
Note: Allow slack in all cables to avoid tension in the cables as the cable-management arm moves.
Figure 23. Mounting bracket pin extended and mounting bracket installed into slide rail
Figure 24. Cable-management arm connection
40 Power Systems: Installing and configuring the Hardware Management Console
