Panel icon messages
The following illustration shows an example of the LCD display. The following
table shows the available icons that display in the LCD.
Power is off Online
Full and idle
Unloading a tape
Seeking data on a
tape
Writing data to a
tape
Failed, offline
Failed, online
Offline
Needs to be cleaned
Tape is cleaning a
drive
Rewinding a tape
Reading a tape
Erasing a tape
Tape is write
protected
Loading a tape
Empty
Library status - failed
Library status - healthy
Library status -
partially available
Menu Commands and structures
This section describes the structure of menu commands.
Menu Command Nesting
Each level of the password-protected menus (Administration and Service) includes
all options available in the subordinate menu. For example, all options available in
the Administration Menu are also included in the Service Menu. This
functionality reduces the need to return to the Main Menu or re-enter the
password. The following figure displays the top level menu items and their
corresponding nested submenus.
Note: The front panel display returns to the Home screen if a button is not pressed
for 3 minutes.
14 LTO Autoloader: User’s Guide
