aligns with the bracket hole. Insert the tab into the hole and turn the bracket (2) to secure it to the
support arm.
3. To attach the other side of the support arm to the backside of the slide rail, pull the pin out (1), and
then slide the bracket (2) into the left slide rail.
4. Pull out the mounting bracket pin (1) and slide the mounting bracket (2) into the right slide rail. Push
the bracket into the slide rail until the spring-loaded pin snaps into place.
Figure 11. Cable-management stop bracket secured to the support arm
Figure 12. Pin extended, bracket installed into slide rail
18 Power Systems: Installing the IBM Power 720 Express (8202-E4B) and IBM Power 740 Express (8205-E6B)
