Environmental requirements
Condition Operational Non-operational
Ambient temperature 0°C to 40°C (32°F to 104°F) -25°C to 70°C (-13°F to 158°F)
Relative humidity
(non-condensing)
10% to 85% at 40°C (104°F) 10% to 90% non-condensing
Altitude (above sea
level)
0 to 3000 m (9,842 feet) 0 to 12000 m (39,370 feet)
Shock 20.0 G, 6 ms, half-sine wave 33.0 G, 11 ms, half-sine wave, 3G Axis
Vibration 0.5 G sine, 0.4 gms random, 5 – 500 Hz 2.0 G sine, 1.1 gms random, 5 – 500 Hz
Airflow Maximum: 387.37 cmh (228 cfm)
Nominal: 227.67 cmh (134 cfm)
N/A
Heat dissipation Refer to the Power consumption table N/A
Operating noise Maximum: 74.2 dB with intake airflow
Maximum: 71.1 dB with exhaust airflow
N/A
Power supply specifications (per PSU)
Power supply
model
Maximum
output
power
rating (DC) Input voltage
Input line
frequency
Maximum
input
current
Input line
protection Maximum inrush current
XBR-
1500WPSAC-F
1500 W 100 – 240 VAC
(nominal)
90 – 264 VAC
(range)
50/60 Hz
(nominal)
47 – 63 Hz
(range)
12 A - 7A Line fused 40 A peak
Note: Do not repeat
plug-in and plug-out
operations within a short
time, or else the internal
inrush current limiting
device (NTC) may not
sufficiently cool down
and may result in
excessive inrush current.
XBR-
1500WPSAC-R
1500 W 100 – 240 VAC
(nominal)
90 – 264 VAC
(range)
50/60 Hz
(nominal)
47 – 63 Hz
(range)
12 A - 7 A Line fused 40 A peak
Note: Do not repeat
plug-in and plug-out
operations within a short
time, or else the internal
inrush current limiting
device (NTC) may not
sufficiently cool down
and may result in
excessive inrush current.
Power consumption (typical configuration)
Model name
@100 VAC
input
@200 VAC
input
Minimum number
of power supplies Notes
SAN128B-6
switch
5.415 A
536 W
1829.41 BTU/hr
2.682 A
522 W
1781.63 BTU/hr
1 (Input current is for
1 PSU. Watts and
BTUs/hr are with 2
PSUs).
25% of ports loaded and operating at
32 Gbps traffic rate, fans at nominal
speed, and input power +/- 5%
tolerance.
Appendix A. Product specifications 83
