Port speed
(Gbps)
Cable size
(microns) Short wavelength (SWL)
Long wavelength
(LWL)
Extended long
wavelength (ELWL)
10 50 82 m (269 ft) (OM2)
300 m (984 ft) (OM3)
550 m (1,804 ft) (OM4)
N/A N/A
62.5 33 m (108 ft) N/A N/A
9 N/A 10 km (6.2 miles) N/A
16 50 35 m (115 ft) (OM2)
100 m (328 ft) (OM3)
125 m (410 ft) (OM4)
N/A N/A
62.5 15 m (49 ft) N/A N/A
9 N/A 10 km (6.2 miles) 25 km (15.5 miles)
32 50 70 m (230 ft) (OM3)
100 m (328 ft) (OM4)
N/A N/A
62.5 N/A N/A N/A
9 N/A 10 km (6.2 miles) 25 km (15.5 miles)
Serial port specifications (pinout RJ-45)
Pin Signal Description
1 Not supported N/A
2 Not supported N/A
3 TXD Transmit data (output from
SAN128B-6)
4 GND Logic ground
5 GND Logic ground
6 RXD Receive data (input into SAN128B-6)
7 Not supported N/A
8 Not supported N/A
Note: These specifications are for the serial connector on IBM platforms only.
Serial port specifications (protocol)
Parameter Value
Baud 9600
Data bits 8
Parity None
Flow control None
Stop bits 1
Appendix A. Product specifications 85
