5. From the rear of the control enclosure, check the LEDs on each node canister
(see Figure 25).
▌1▐ Power
▌2▐ Status
▌3▐ Fault
The canister is ready with no critical errors when Power is illuminated, Status
is flashing, and Fault is off. If a canister is not ready, refer to the “Procedure:
Understanding the system status using the LEDs” topic in “Troubleshooting”.
v3500064
2
3
1
Figure 25. Node canister LEDs
28 Storwize V5000: Quick Installation Guide

IBM Storwize V5000 Specifications

General

Storage Type	Hybrid Flash Array
Maximum Drives	240
Form Factor	2U
Model	IBM Storwize V5000
Drive Types	SSD, HDD
RAID Levels	RAID 0, 1, 5, 6, 10
Host Interface	8 Gbps Fibre Channel (FC), 12 Gbps SAS, 10 Gbps iSCSI, 16 Gbps FC
Software Features	Thin provisioning
Drive Bays	12 or 24
Cache	Up to 32GB
Cache Memory	Up to 32GB
Weight	30kg (66.1lb)
Power Supply	Dual
Cooling	Redundant cooling fans
Dimensions	88mm x 482mm x 740mm (3.5in x 19in x 29.1in)
