a. Press the catch to release the handle 1.
b. Lift the handle on the battery 2.
c. Lift the battery out of the power supply unit 3.
4. Install the replacement battery.
Attention: The replacement battery has protective end caps that must be
removed prior to use.
a. Remove the battery from the packaging.
b. Remove the end caps.
c. Attach the end caps to both ends of the battery that you removed and place
the battery in the original packaging.
2
svc00611
3
1
Figure 59. Removing the battery from the control enclosure power-supply unit
224 Storwize V7000 Unified: Problem Determination Guide Version

IBM Storwize V7000 2076-324 Specifications

General

RAID Levels	RAID 0, 1, 5, 6, 10
Maximum Drives Supported	504
Drive Bays	24
Product Type	Storage system
Form Factor	2U
Drive Type Supported	SAS, NL-SAS, SSD
Host Interfaces	8 Gbps Fibre Channel, 1 Gbps iSCSI, 10 Gbps iSCSI
Cache Memory	32 GB
Operating System	IBM SAN Volume Controller
