Record Storwize V7000 Gen1 node canister Ethernet port connections with Table 9.
Table 9. Storwize V7000 Gen1 node canister Ethernet port connections
Node
canister Ethernet port 1 Ethernet port 2 Ethernet port 3 Ethernet port 4
Node
canister 1
(upper)
switch:
port:
speed: 10 Gbps 10 Gbps
Node
canister 2
(lower)
switch:
port:
speed: 10 Gbps 10 Gbps
Record Storwize V7000 Gen2 node canister Ethernet port connections with
Table 10.
Table 10. Storwize V7000 Gen2 node canister Ethernet port connections
Node
canister
Ethernet
port 1
Ethernet
port 2
Ethernet
port 3
Ethernet
port 4
Ethernet
port 5
Ethernet
port 6
Ethernet
port 7
Node
canister 1
(left)
switch:
port:
speed: 10 Gbps 10 Gbps 10 Gbps 10 Gbps
Node
canister 2
(right)
switch:
port:
speed: 10 Gbps 10 Gbps 10 Gbps 10 Gbps
Note: Fibre Channel is standard.
Record node canister Fibre Channel port connections with Table 11, Table 12 on
page 13, and file module Ethernet connections with Table 13 on page 13.
Table 11. Storwize V7000 Gen1 node canister Fibre Channel port connections
Node
canister Fibre Channel port 1 Fibre Channel port 2 Fibre Channel port 3 Fibre Channel port 4
Node
canister 1
(upper)
switch
or host:
File module 1 File module 2
port: 1 1
speed: 8 Gbps 8 Gbps
Node
canister 2
(lower)
switch
or host:
File module 1 File module 2
port: 2 2
speed: 8 Gbps 8 Gbps
12 IBM Storwize V7000 Unified: Adding Storwize V7000 File Modules to an existing Storwize V7000 system 2073-720

IBM Storwize V7000 Unified Specifications

General

Model	IBM Storwize V7000 Unified
Storage Type	Unified Storage
RAID Levels	RAID 0, 1, 5, 6, 10
Form Factor	2U
Drive Types Supported	SAS, SSD
Maximum Drives	504
Network Protocols	iSCSI, FC, FCoE
Drive Bays	24 per enclosure
Host Interface	8 Gb FC, 1 Gb/10 Gb iSCSI
File Protocols	NFS, CIFS
Block Protocols	iSCSI, Fibre Channel
Type	Unified Storage
Maximum Host Ports	16
Operating System Support	VMware, Microsoft Windows, Linux, AIX
Data Services	Thin provisioning, replication
Power Supply	Redundant power supplies
Host Interfaces	8 Gbps Fibre Channel, 10 Gbps iSCSI, 1 Gbps iSCSI
