3. Remove the screws A (Figure 9) that secure the cover; then, remove the cover B (Figure 9) from
the tray by lifting it straight up and off the tray. The fiscal memory is epoxied to the inside of the cover
and also connects to the fiscal logic card. The fiscal memory prevents the cover from being easily
removed.
A
Figure 9. Removing the fiscal tray cover.
Removing and replacing FRUs
32
SureMark Hardware Service
