IBM System x3100 M4 Type 2582 Problem Determination And Service Guide

Table 1. Features and specifications for 4U server models with non-hot-swap power supplies. For the 5U server
model with hot-swap power supplies (Model name: 2582-F4x), please see Table 2. (continued)
Drives (depending on the model):
v Hard disk drives: up to four 3.5-inch
simple-swap SATA
v One of the following SATA attached
optical drives:
– DVD-ROM
Drive bays:
v Two 5.25-inch half-high bays (one
optical drive installed).
v Four 3.5-inch hard disk drive bays
Integrated functions:
v Integrated management module II
(IMM2), which consolidates multiple
management functions in a single chip
v Intel 82574L Gb Ethernet controller with
TCP/IP Offload Engine (TOE) and Wake
on LAN support
v Integrated SATA controller
v Seven Universal Serial Bus (USB) 2.0
ports (two front, four rear of the chassis,
and one internal for an optional tape
drive)
v Six SATA ports (four for simple-swap
hard disk drives and two for the DVD
drive and the optional tape drive)
v One serial port
v Two Ethernet port
v One VGA port
Heat output:
Approximate heat output:
v Minimum configuration: 119 Btu per
hour (35 watts)
v Maximum configuration: 1194 Btu per
hour (350 watts)
Electrical input:
v Sine-wave input (50 or 60 Hz) required
v Input voltage and frequency ranges
automatically selected
v Input voltage low range:
– Minimum: 100 V ac
– Maximum: 127 V ac
v Input voltage high range:
– Minimum: 200 V ac
– Maximum: 240 V ac
v Input kilovolt-amperes (kVA)
approximately:
– Minimum: 0.035 kVA (all models)
– Maximum: 0.350 kVA
Expansion slots:
v One PCI Express x16 slot
v One PCI Express x8 slot
v One PCI Express x4 slot
v One PCI Express x1 slot
Acoustical noise emissions:
v Sound power, idling: 4.5 bels
v Sound power, operating: 4.8 bels
Notes:
1. Power consumption and heat output
vary depending on the number and
type of optional features installed and
the power-management optional
features in use.
2. The noise emission level stated is the
declared (upper limit) sound power
level, in bels, for a random sample of
machines. All measurements are
made in accordance with ISO 7779
and reported in conformance with ISO
9296.
8 IBM System x3100 M4 Type 2582: Problem Determination and Service Guide
