Table 2. Features and specifications for the 5U server model with hot-swap power supplies (Model name: 2582-F4x).
For 4U server models with non-hot-swap power supplies, please see Table 1.
Microprocessor:
v Supports one Intel quad-core (Xeon
E3-1200 series) or dual-core (Pentium
G850, or Core i3 series) processor
v Multi-chip Package processor
architecture
v Designed for LGA 1155 socket
v Scalable up to four cores
v 32 KB instruction L1 cache, 32 KB data
L1 cache, 256 KB instruction/data L2
cache, and up to 8 MB L3 cache that is
shared among the cores
v Support for Intel Extended Memory 64
Technology (EM64T)
Note:
v Use the Setup utility to determine the
type and speed of the microprocessor.
v For a list of supported microprocessors,
see http://www.ibm.com/servers/eserver/
serverproven/compat/us/.
Memory:
v Connectors: four dual inline memory
module (DIMM) connectors, two-way
interleaved
v Minimum: 1 GB
v Maximum: 32 GB
v Types: PC3-12800 (single-rank or
dual-rank), 1066, 1333 and 1600 MHz,
ECC, DDR3 unbuffered SDRAM DIMMs
only
v Sizes: 1GB (single-rank) 2GB
(single-rank) 4GB (dual-rank) 8GB
(dual-rank)
Fan:
v One system fan
Power supply: One or two redundant
430-watt power supply
Size:
v Height: 438.60 mm (17.27 in.)
v Depth: 569.11 mm (22.41 in.)
v Width: 217.25 mm (8.56 in.)
v Weight: 19.6 kg (43 lb) to 21.4 kg (47
lb) depending upon configuration
RAID (depending on model):
v ServeRAID-BR10il v2 SAS/SATA
adapter that provides RAID levels 0, 1,
and 10.
Environment:
v Air temperature:
– Server on: 10°C to 35°C (50°F to
95°F)
Altitude: 0 to 914.4 m (3000 ft)
– Server on: 10°C to 32°C (50°F to
89.6°F)
Altitude: 914.4 m (3000 ft) to 2133.6
m (7000 ft)
– Server on: 10°C to 28°C (50.0°F to
83°F); altitude: 2133.6 m (7000 ft) to
3050 m (10000 ft)
– Server off: 10°C to 43°C (50°F to
109.4°F)
– Shipping: -40°C to 60°C (-40°F to
140°F)
v Humidity (operating and storage): 8%
to 80%
v Particulate contamination:
Attention: Airborne particulates and
reactive gases acting alone or in
combination with other environmental
factors such as humidity or temperature
might pose a risk to the server. For
information about the limits for
particulates and gases, see “Particulate
contamination” on page 299.
Drives (depending on the model):
v Hard disk drives: up to eight 2.5-inch
hot-swap SATA
v One of the following SATA attached
optical drives:
– DVD-ROM
Drive bays:
v Two 5.25-inch half-high bays (one
optical drive installed).
v Eight 2.5-inch hard disk drive bays
Integrated functions:
v Integrated management module II
(IMM2), which consolidates multiple
management functions in a single chip
v Intel 82574L Gb Ethernet controller with
TCP/IP Offload Engine (TOE) and Wake
on LAN support
v Integrated SATA controller
v Seven Universal Serial Bus (USB) 2.0
ports (two front, four rear of the chassis,
and one internal for an optional tape
drive)
v Six SATA ports (blue-colored ports for
DVD drive or optional tape drive)
v One serial port
v Two Ethernet port
v One VGA port
Heat output:
Approximate heat output:
v Minimum configuration: 341 Btu per
hour (100 watts)
v Maximum configuration: 1726 Btu per
hour (506 watts)
Electrical input:
v Sine-wave input (50 or 60 Hz) required
v Input voltage and frequency ranges
automatically selected
v Input voltage low range:
– Minimum: 100 V ac
– Maximum: 127 V ac
v Input voltage high range:
– Minimum: 200 V ac
– Maximum: 240 V ac
v Input kilovolt-amperes (kVA)
approximately:
– Minimum: 0.100 kVA (all models)
– Maximum: 0.506 kVA
Chapter 2. Introduction
9
To Next Page
