IBM System x3400 M3 Types 7378 User Manual

Power-supply
cage handle
Power-supply cage
Power-supply cage
front latch bracket
Locating tabs
Locating tabs
Notch
3. Rotate the power-supply cage handle down until the handle tip engages the
notch in the front latch bracket; then, lower the handle until it locks in place.
Power supply
cage closed
4. Install and lock the left-side cover (see “Completing the installation” on page
98).
5. Install the hot-swap power supplies.
6. Reconnect the external cables and power cords; then, turn on the attached
devices and turn on the server.
Chapter 2. Installing optional devices 57

IBM System x3400 M3 Types 7378 Specifications

General

Processor	Intel Xeon 5600 series
Memory Slots	12 DIMM slots
Hard Drive Bays	Up to 8 bays
Network Interface	Dual Gigabit Ethernet
Management	Integrated Management Module (IMM)
Form Factor	Tower
Processor Cores	4 or 6 cores
Chipset	Intel 5520
Storage	SAS/SATA
RAID Support	RAID 0, 1, 10
Power Supply	Redundant Power Supply Options Available
Expansion Slots	4 PCI-Express slots
USB Ports	6 USB 2.0
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
