Virtual media
key connector
Virtual media
key (front)
Virtual media
key (rear)
Retention
tab
Alignment
bracket
2. Reinstall any adapters that you removed.
3. Close the rear adapter-retention bracket.
4. Install and lock the left-side cover (see “Completing the installation” on page
98).
5. Lock the left-side cover.
6. Reconnect the external cables and power cords; then, turn on the attached
devices and turn on the server.
Chapter 2. Installing optional devices 83
