Notes:
1. The LCD front cover has several latches. Release
the latches as shown in the figure in step .3/.
2. When replacing the control knob in step .4/, make
sure that it works correctly.
Step Size (Quantity) Torque
.2/ M 2.5 x 6mm (2) 4 kgcm
Note: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you
removed, use a new screw.
ThinkPad 380, 385 (2635) 91
