2040 LCD Misc. Parts
 Battery Pack (1010)
 DIMM Cover (1020)
 Keyboard Unit (1030)
 CD-ROM/FDD Assembly (1040)
 LCD Unit (1070)
 LCD Front Cover (2010)
 LCD Panel (2020)
 LCD Inverter Card (2030)
Hinges/Latches DSTN LCD
.1/.2/.3/.4/: Hinges
.5/.6/: Latches
Step Size (Quantity) Torque
.1/ (a) M 2.5 x 6mm (2)
(b) M 2.5 x 6mm, Special head (1)
4 kgcm
.2/ M 2.5 x 6mm (2) 4 kgcm
Note: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you
removed, use a new screw.
96 IBM Mobile Systems HMM
