TFT LCD: This artwork shows the TFT type 1 LCD.
For the type 2, do the same procedure.
.1/.2/.3/.4/: Hinges
.5/.6/: Latches
Step Size (Quantity) Torque
.1/ (a) M 2.5 x 6mm (2)
(b) M 2.5 x 6mm, Special head (1)
4 kgcm
.2/ M 2.5 x 6mm (2) 4 kgcm
Note: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you
removed, use a new screw.
ThinkPad 380, 385 (2635) 97
