1125 Upper Shield
 Diskette Drive/CD-ROM Drive (1020)
 Battery Pack (1030)
 Hard Disk Drive (1040)
 Top Cover (1060)
 Keyboard Unit (1070)
 LCD Unit (1080)
 Front IR and Rear IR (1090)
 System Board Assembly (1100)
Step Size (Quantity) Torque
.1/ 6mm, Nylon (4) 4 kgcm
Note: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you
removed, use a new screw.
266 IBM Mobile Systems HMM
To Next Page
