1190 System Board
 Battery Pack (1010)
 UltraBay II Device or 2nd Battery Pack (1020)
 Hard Disk Drive (1040)
 Keyboard Unit (1060)
 Hinge Cover and Center Cover (1070)
 Eject Lever and Power Switch (1080)
 LCD Unit (1090)
 Standby Battery (1100)
 Upper Shield (1110)
 Video Card (1130)
 Modem Card (1140)
 DC/DC Card (1150)
 Fan (1160)
 CPU Card (1170)
 PC Card Slot (1180)
Step Size (Quantity) Color Torque
.1/ M2.5 x 4 mm, Nylon
(3)
Yellow 4 kgcm
.2/ M2.5 x 6 mm, Nylon
(1)
Black 4 kgcm
Note: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you
removed, use a new screw.
ThinkPad 770 (9548, 9549) 599
