9020 LCD Panel
 LCD Cover (9010)
Note
Be careful not to scratch or soil the surface of the LCD
panel when replacing it.
Lift the LCD panel a bit and disconnect the connector for
the interface cable. If there is the kapton tape on the rear
of the panel, remove it.
Step Length (Quantity) Memo
.1/ M2.5 x 6 mm (2)
Note: Make sure you use the correct screw when replacing.
ThinkPad 760 (9546, 9547) 337
