TFT
 .1/.2/: LCD cable
 .3/.4/: Hinges
When replacing:
See the following figure:
Step Size (Quantity) Torque
.1/ M 2.5 x 6 mm, flathead (2) 3.0 kgcm
.3/ M 2.5 x 6 mm (3)
flathead
3.0 kgcm
Note: Make sure you use the correct screw and tighten it to
the torque specified. Do not use the screw that you removed,
use a new screw.
182 IBM Mobile Systems HMM
