 760XL
Note: Be careful not to touch the fan rotor when
assembling or disassembling.
When replacing:
The following figure shows the microphone routing.
Step Size (Quantity) Torque
.3/ 4mm, Nylon (2) 4 kgcm
Note: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you
removed, use a new screw.
268 IBM Mobile Systems HMM
