Pull
the
corner
of
the
base
cover
indicated
by
arrow
6
to
unlatch
the
claw
a
.
6
a
In
step
7
,
make
sure
that
all
of
the
claws
(
b
)o
nt
h
e
front
side
of
the
computer
are
detached,
and
then
remove
the
keyboard
bezel
in
the
direction
of
arrow
8
.
8
7
b
b
b
b
b
b
Removing
and
replacing
a
FRU
90
ThinkPad
T30
(MT
2366,
2367)
93
95
