1030 DIMM cover
For access, remove following FRU:
v “1010 Battery pack” on page 76
Note:
Loosen the screws 1, but do not remove them.
2
1
1
1
3
Step Screw (quantity) Torque
1 M2 ×3 mm (3) 0.157 Nm
(1.6
kgfcm)
Removing and replacing a FRU
78 MT 2369/2370/2371/2372/2382/2386
