1060
Upper
case
For
access,
remove
following
FRUs,
in
order:
v
“1010
Battery
pack”
on
page
76
v
“1050
Keyboard”
on
page
82
Remove
6
screws
as
shown
below
.
1
1a
1
1
1
1
1
Step
Screw
(quantity)
T
orque
1
M2
×
6
mm,
nylon-coated
(6)
0.196
Nm
(2
kgfcm)
(continued)
Removing
and
replacing
a
FRU
ThinkPad
X40
85
88
90
