Biotech-Lab User Manual \\ 15www.ibpmedical.com
This readout is a typical one value displaywithout any additional special
functionality in the display area.
Shows graph of all values
Shows statistic values of all Sensors
6.3 VALUE DISPLAY AREA FUNCTIONALITY
Depending on the connected device different readouts are shown.
Element Function
This is a typical two value display. L acc is the accumulated amount in L.
This is a typical two value display with an additional functionality in
the headline. “Dialysis Machine Standard” indicates here Nthe selected
conductivity temperature compensation coefficient.
Shows settings for the particular device.
For sensors a single sensor graphic is shown.
In case a sensor is disconnected the system scanns the sensor ports automaticaly.
During the scan all visibla sensor values are shown as “ - - - “.
Shows additional features of the particular device. To return
to the list view, press the button again.
