8 HDC75 Display and Control Unit
8.2 TECHNICAL DATA
Computer CPU Intel Atom Z3735G (1.33GHz)
Screen 7” diagonal HD WXGA
IPS multi touch, 1280 x 800,
Memory 32 GB Flash Memory,
1 GB DDR3L SDRAM
32 GB Flash Memory Card
OS Microsoft Windows 10
Network WLAN 802.11 b/g/n
Camera 0.3 MP fixed focus (front-facing);
2 MP fixed focus (rear-facing)
Audio Mono speaker
Interface Micro USB-B Host, also charger connector
5 x RS485, M8 Connector for Biotech-Lab Modules
Degree of Protection IP54
Power Supply 3,7 V / 14000 mHh (52 Wh) Li-ion polymer battery
Quick Charge 2.0 compatible
Environmental Conditions Operating Temperature Range: 0 to 50°C
Storage Temperature Range: -40 to 80°C
Operating and Storage Humidity:
85% max relative humidity non-condensing from 0 to 50°C
Dimensions 250 x 140 x 50 mm
Weight 1,7 Kg
