Icematic M402 - Wiring Diagram

English
19
SERVICE MODULARI 06/2014
A - Input terminal board
B- Compressor remote control switch
C- Compressor
D- Ice sensor
E- End defrosting switch
F- Water level sensor
G- Condenser temperature probe
H- Led card
I-Electronic card
J- Max pressure switch
K- Automatic reset switch
L- Water pump
M- Water inlet valve
N- Water discharge valve
O- Hot gas valve
SP- Solenoid harv assist
P- Fan Motor (only AIR cooled unit)
Q- Fan Motor (only WATER cooled unit)
RC - Compressor relay
CS - Start condenser
CM - Run condenser
m=brown
bc = light blue
gv = yellow green
b=white
n=black
r=red
a
= orange
v=viola
L
SP
F
E
G
v
v
bc
m
bc
n
b
r
a
m
n
bc
n
n n
bcm
bc
n
bc
n
v
v
N
b
bc
M
r
bc
D
m
P1
P2
A
Wiring Diagram M202 - M302 -M402
220V / 50Hz / 1ph
