IceTech PR350H - Page 127

1
4
3
2
B
REVISIONS
REV. DESCRIPTION DATE
A
B Pos. 1 updated. 04-05-2011 PJ
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 502276 Bracket for outlet sprout PR750H 1
2 502277 Outlet sprout for PR750H 1
3 502278 Clamp gasket ISO 1127 1
4 502279 Clamp Ø138 1
27-04-11
ICETECH A/S
Drawing no.:
pj
Format:
Cpl. bracket and outlet sprout.
Description:
1:2
kg
Weight:
Scale:
Date:
B
Rev:
