Parts Diagrams
SC2000 SC2001
Battery
Compartment
G O B Y C RW
NON HP–HP
GAS
ELEC
SC2001
G O B Y RH RCW
RH RC
NON HP–HP
SC2000
GAS
ELEC
Reset Switch
Electric/Gas
Jumper
Mode
Switch
Fan
Switch
Freeze
Switch
High Temp.
Switch
Non HP – HP
Jumper
Electric/Gas
Jumper
Mode
Switch
Fan
Switch
Freeze
Switch
High Temp.
Switch
Non HP – HP
Jumper
RH RC
Switch
