Icom IC-208H - SOFTWARE ADJUSTMENTS (TRANSMITTING AND RECEIVING)

5 - 4
SOFTWARE ADJUSTMENTS (TRANSMITTING AND RECEIVING)–Continued
FREQUENCY
DEVIATION
(VHF band)
[DE]
(UHF band)
[DE]
DTCS WAVE
FORM
(VHF band)
[DE]
(UHF band)
[DE]
TRACKING
(Low band)
[Tr]
(Middle1
band)
[Tr]
1
2
3
4
1
2
1
2
3
4
5
6
7
8
• Operating frequency : 144.0 MHz
• Connect an audio generator to the [MIC] jack and set
as : +20 dB
• Connect an FM deviation meter to the antenna con-
nector and set as :
HPF : 50 Hz
LPF : 20 kHz
De-emphasis : OFF
Detector : (P–P)/2
• Transmitting
• Operating frequency : 148.0 MHz
• Transmitting
• Operating frequency : 440.0 MHz
• Transmitting
• Operating frequency : 450.0 MHz
• Transmitting
• Operating frequency : 146.0 MHz
• No audio signal is applied to the [MIC] jack.
• DTCS code : 007
• Set an FM deviation meter as:
HPF : OFF
LPF : 20 kHz
De-emphasis : OFF
Detector : (P–P)/2
• Transmitting
• Operating frequency : 445.0 MHz
• Transmitting
• Operating frequency : 118.1 MHz
• Connect an SSG to the antenna connector and set as
Level : 1 µV* (–107 dBm)
Modulation : 1 kHz
Deviation : ± 3.5 kHz
• Receiving
• Operating frequency : 146.1 MHz
• Receiving
• Operating frequency : 160.1 MHz
• Receiving
• Operating frequency : 173.9 MHz
• Receiving
• Operating frequency : 230.1 MHz
• Connect an SSG to the antenna connector and set as
Level : 1 µV* (–107 dBm)
Modulation : 1 kHz
Deviation : ± 3.5 kHz
• Receiving
• Operating frequency : 260.1 MHz
• Receiving
• Operating frequency : 380.1 MHz
• Receiving
• Operating frequency : 399.9 MHz
• Receiving
• Turn the [DIAL] to set to ±4.6 kHz.
• Push the [BAND] key.
• Turn the [DIAL] to set to ±4.6 kHz.
• Push the [BAND] key.
• Turn the [DIAL] to set to ±4.6 kHz.
• Push the [BAND] key.
• Turn the [DIAL] to set to ±4.6 kHz.
• Push the [BAND] key.
• Turn the [DIAL] to set to flat wave form as shown
below.
• Push the [BAND] key.
• Turn the [DIAL] to set to flat wave form as same as
VHF band.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
ADJUSTMENT ADJUSTMENT CONDITION OPERATION
*This output level of a standard signal generator (SSG) is indicated as SSG’s open circuit.
Set to flat wave
form
