Icom IC-2820H - Page 27

6
1
PANEL DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
@3FREQUENCY MARKER (p. 27)
Gap shows the selected frequency in the band scope.
@4CENTER FREQUENCY MARKER
Dotted line shows the center frequency of the band scope.
@5BAND SCOPE INDICATOR
When the band scope function is in use, shows the band
conditions.
@3
@4
@5
Function guide indications (pgs. 7, 8)
